KLIPSCH Heresy IV

$8,398.00
(No reviews yet) Write a Review
SKU:
HeresyIV
KLIPSCH Heresy IV

HERESY IV



First introduced in 1957, the Heresy, a three-way design, started out as a compact center channel speaker to accompany the Klipschorn® in three-speaker stereo arrays. The Heresy IV offers unparalleled sound quality from a relatively small speaker.

Features:

  • Includes New 10-Year Warranty

  • All-new K-702 midrange compression driver, featuring a polyimide diaphragm, for exceptional detail

  • For the first time, the Heresy IV features a rear port for the most efficient, fastest air transfer in their class, which reduces port noise for punchier low frequencies

  • K-702 midrange is mated to the K-704 Tractrix® horn for a wide coverage pattern

  • K-107-TI titanium diaphragm high-frequency driver with an all-new wide dispersion phase plug for providing exceptionally even high-frequency dispersion

  • All-new high fidelity network for truer to life sound, best-in-class efficiency, and power handling

  • Klipsch Tractrix ports have custom-designed inner flares that help reduce air turbulence entering the port. Less turbulent air helps reduce port noise for cleaner, more powerful bass

  • Available in a high-quality Satin Black Ash, Natural Cherry, Distressed Oak, or American Walnut wood veneer finish

  • Designed & assembled in the USA

A LITTLE HERESY IS GOOD FOR THE SOUL

The Heresy IV is quite possibly the speaker champion of the world.

Whether it's for your burgeoning vinyl collection, home theater or whatever, the Heresy IV will knock your socks off.

DESIGNED & ASSEMBLED IN THE USA. MADE TO ROCK.

With cabinetry that is proudly handcrafted in Hope, Arkansas for over 50 years, the Klipsch Heresy IV speaker is a testament to the quality Klipsch demands from each and every of its audio products.

Here's to 50 more years of Heresy.

For the first time in its long legacy, the Heresy now features a rear port – improving low-frequency extension by almost 10Hz, for room-filling bass.

Utilizing Tractrix geometry, the all-new Heresy IV ports allow for the most efficient, fastest air transfer in their class, which reduces port noise for punchier low frequencies. Klipsch Tractrix ports have custom designed inner flares that help reduce air turbulence entering the port. Less turbulent air helps reduce port noise for cleaner, more powerful bass.

In addition to delivering smooth, dynamic and low distortion sound, the Heresy IV is available in a high-quality Natural Cherry, Distressed Oak, American Walnut, or Satin Black Ash wood veneer finish. A slant riser base is included for floor placement that can be removed for cabinet installations.

 THE ORIGINAL HI-FI HOT ROD First introduced in 1957, the Heresy® was arguably the first ever center channel loudspeaker, used with the Klipschorn in three-speaker stereo arrays. Topping many audiophiles’ best rock-n-roll speaker lists because of its incredible output and clarity, the Klipsch Heresy is a compact, three-way design that uses horn-loaded compression drivers for midrange and treble reproduction, and a direct radiating 12-inch woofer for the low frequencies.



SPECIFICATIONS

FREQUENCY RESPONSE (+/- 4 dB) 48-20k +/-4dB

SENSITIVITY 99dB @ 2.83V / 1m

POWER HANDLING (CONT/PEAK) 100W/400W

MAXIMUM SPL 116dB Continuous

NOMINAL IMPEDANCE 8 ohms Compatible

CROSSOVER FREQUENCY HF: 4500Hz MF: 850Hz

HIGH FREQUENCY DRIVER K-107-TI 1” (2.54cm) Titanium diaphragm compression driver

MIDRANGE K-702 1.75” (4.45cm) polyimide diaphragm compression driver

LOW FREQUENCY DRIVER K-28-E 12” (30.48cm) Fiber-composite cone woofer

ENCLOSURE MATERIAL MDF

INPUTS Dual binding posts / bi-wire / bi-amp

HEIGHT 63.01cm

WIDTH 39.37cm

DEPTH 33.66cm

WEIGHT 20.41kg
